Numerical System

This panel is used to demonstrate the number systems such as binary, decimal, and hexadecimal numbers. Toggle switches are used to activate the displays showing the particular number entered. Input may be entered either as decimal or binary numbers with a toggle switch for mode selection. Decimal numbers are shown on a three-digit seven-segment LED display. Operates on 220V.
