STUDENT MICROSCOPE MODEL |
|
General Features
- Pressure die-cast parts to ensure strength and
uniformity.
- Well proportioned stable, rigid and vertical body
inclinable through 90.
- Mechanical tube length 160 mm.
- Separate knobs for coarse and fine focussing.
Coarse knobs are with tension adjustment
arrangement.
- Triple revolving nose-piece with international
standard threads, with click stops ensuring correct
centering.
- High grade achromatic objectives and Huygenian
eye-pieces for sharp and aberration free image
- Safety stopper to prevent damage to slides and
objectives.
- Fixed square stage of 110x110 mm with two nonremovable
stage clips.
- Sub-stage plano concave daylight mirror reflector in
metal mount, replaceable by an electrical illuminator.
- Smooth black or scratch resistant grey epoxy finish.
- Dust cover and cleaning cloth.
- Packed in moulded styrofoam box or wooden cabinet
with lock and key.
OPTICS
|
Eye-pieces
|
: Huygenian x10 and x15
|
|
Objectives
|
: Achromatic x10, and x40 (SL)
|
|
Magnification
|
: x100 to x600
|
As above, but stage fitted with iris diaphragm, Abbe condenser N.A 1.2, with rack and pinion movement.
|
|
| |
|
