Microscopes

‘Supertek’ Microscopes are a class by themselves. Manufactured under an ISO 9001 standardized system, each operation is carefully carried out and monitored. Due consideration is given to the parameters involved. The components and the final products are subjected to various tests commensurate with the quality of the microscope. While each microscope is inspected, the advanced microscopes are subjected to a whole series of tests such as freedom from optical aberrations, resolving power etc.
These microscopes are designed to require minimum maintenance and incorporate devices to guard against over-enthusiastic use by students. For the safety of the object slide, objective lens and the mechanism, it is recommended that observing from the side, the objective lens should be brought close to the object and then looking down the microscope, focussing should be done by racking the objective away from the object.
Low cost basic equipment for use by school children to study natural science. Its light weight makes it suitable for field work as well. Focussing is by rack and pinion movement. A 84 x 76 mm stage with disc diaphragm and slide holding clips is provided. Illumination is by plano concave mirror reflector fitted under the stage. One Huygenian eye-piece x10 and one achromatic objective x10 are provided to give a sharp image of x100 magnification.‘Supertek’ Microscopes are a class by themselves. Manufactured under an ISO 9001 standardized system, each operation is carefully carried out and monitored. Due consideration is given to the parameters involved. The components and the final products are subjected to various tests commensurate with the quality of the microscope. While each microscope is inspected, the advanced microscopes are subjected to a whole series of tests such as freedom from optical aberrations, resolving power etc.
These microscopes are designed to require minimum maintenance and incorporate devices to guard against over-enthusiastic use by students. For the safety of the object slide, objective lens and the mechanism, it is recommended that observing from the side, the objective lens should be brought close to the object and then looking down the microscope, focussing should be done by racking the objective away from the object.
Low cost basic equipment for use by school children to study natural science. Its light weight makes it suitable for field work as well. Focussing is by rack and pinion movement. A 84 x 76 mm stage with disc diaphragm and slide holding clips is provided. Illumination is by plano concave mirror reflector fitted under the stage. One Huygenian eye-piece x10 and one achromatic objective x10 are provided to give a sharp image of x100 magnification.

‘Supertek’ Microscopes are a class by themselves. Manufactured under an ISO 9001 standardized system, each operation is carefully carried out and monitored. Due consideration is given to the parameters involved. The components and the final products are subjected to various tests commensurate with the quality of the microscope. While each microscope is inspected, the advanced microscopes are subjected to a whole series of tests such as freedom from optical aberrations, resolving power etc.
These microscopes are designed to require minimum maintenance and incorporate devices to guard against over-enthusiastic use by students. For the safety of the object slide, objective lens and the mechanism, it is recommended that observing from the side, the objective lens should be brought close to the object and then looking down the microscope, focussing should be done by racking the objective away from the object.
Economy model for beginners. Monocular body is inclinable upto 90 for ease of working. Mechanical tube length is standard 160 mm. Focussing is through rack & pinion arrangement. A fixed stage 110 x 100 mm is provided with stage clips ,illumination is by plano concave mirror reflector. With x10 Huygenian eye-piece and x10 achromatic objective, giving x100 magnification.‘Supertek’ Microscopes are a class by themselves. Manufactured under an ISO 9001 standardized system, each operation is carefully carried out and monitored. Due consideration is given to the parameters involved. The components and the final products are subjected to various tests commensurate with the quality of the microscope. While each microscope is inspected, the advanced microscopes are subjected to a whole series of tests such as freedom from optical aberrations, resolving power etc.
These microscopes are designed to require minimum maintenance and incorporate devices to guard against over-enthusiastic use by students. For the safety of the object slide, objective lens and the mechanism, it is recommended that observing from the side, the objective lens should be brought close to the object and then looking down the microscope, focussing should be done by racking the objective away from the object.
Economy model for beginners. Monocular body is inclinable upto 90 for ease of working. Mechanical tube length is standard 160 mm. Focussing is through rack & pinion arrangement. A fixed stage 110 x 100 mm is provided with stage clips ,illumination is by plano concave mirror reflector. With x10 Huygenian eye-piece and x10 achromatic objective, giving x100 magnification.

‘Supertek’ Microscopes are a class by themselves. Manufactured under an ISO 9001 standardized system, each operation is carefully carried out and monitored. Due consideration is given to the parameters involved. The components and the final products are subjected to various tests commensurate with the quality of the microscope. While each microscope is inspected, the advanced microscopes are subjected to a whole series of tests such as freedom from optical aberrations, resolving power etc.
These microscopes are designed to require minimum maintenance and incorporate devices to guard against over-enthusiastic use by students. For the safety of the object slide, objective lens and the mechanism, it is recommended that observing from the side, the objective lens should be brought close to the object and then looking down the microscope, focussing should be done by racking the objective away from the object.
As above, but with triple revolving nose-piece and three achromatic objectives x4, x10 and x20 giving magnification x40 to x200.

‘Supertek’ Microscopes are a class by themselves. Manufactured under an ISO 9001 standardized system, each operation is carefully carried out and monitored. Due consideration is given to the parameters involved. The components and the final products are subjected to various tests commensurate with the quality of the microscope. While each microscope is inspected, the advanced microscopes are subjected to a whole series of tests such as freedom from optical aberrations, resolving power etc.
These microscopes are designed to require minimum maintenance and incorporate devices to guard against over-enthusiastic use by students. For the safety of the object slide, objective lens and the mechanism, it is recommended that observing from the side, the objective lens should be brought close to the object and then looking down the microscope, focussing should be done by racking the objective away from the object.
As above, but with triple revolving nose-piece and three achromatic objectives x4, x10 and x20 giving magnification x40 to x200.

General Features

• Pressure die-cast parts to ensure strength and uniformity.
• Well proportioned stable, rigid and vertical body inclinable through 90.
• Mechanical tube length 160 mm.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
• High grade achromatic objectives and Huygenian eye-pieces for sharp and aberration free image
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.

OPTICS

Eye-pieces	: Huygenian x10 and x15
Objectives	: Achromatic x10, and x40 (SL)
Magnification	: x100 to x600

Description as above, stage fitted with disc diaphragm having six different apertures.

General Features

• Pressure die-cast parts to ensure strength and uniformity.
• Well proportioned stable, rigid and vertical body inclinable through 90.
• Mechanical tube length 160 mm.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
• High grade achromatic objectives and Huygenian eye-pieces for sharp and aberration free image
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.

OPTICS

Eye-pieces	: Huygenian x10 and x15
Objectives	: Achromatic x10, and x40 (SL)
Magnification	: x100 to x600

Description as above, stage fitted with disc diaphragm having six different apertures.

General Features

• Pressure die-cast parts to ensure strength and uniformity.
• Well proportioned stable, rigid and vertical body inclinable through 90.
• Mechanical tube length 160 mm.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
• High grade achromatic objectives and Huygenian eye-pieces for sharp and aberration free image
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.

OPTICS

Eye-pieces	: Huygenian x10 and x15
Objectives	: Achromatic x10, and x40 (SL)
Magnification	: x100 to x600

As above, but stage fitted with iris diaphragm with a substage two-lens Abbe condenser N.A. 1.2, having helical motion.

General Features

• Pressure die-cast parts to ensure strength and uniformity.
• Well proportioned stable, rigid and vertical body inclinable through 90.
• Mechanical tube length 160 mm.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
• High grade achromatic objectives and Huygenian eye-pieces for sharp and aberration free image
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.

OPTICS

Eye-pieces	: Huygenian x10 and x15
Objectives	: Achromatic x10, and x40 (SL)
Magnification	: x100 to x600

As above, but stage fitted with iris diaphragm with a substage two-lens Abbe condenser N.A. 1.2, having helical motion.

General Features

• Pressure die-cast parts to ensure strength and uniformity.
• Well proportioned stable, rigid and vertical body inclinable through 90.
• Mechanical tube length 160 mm.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
• High grade achromatic objectives and Huygenian eye-pieces for sharp and aberration free image
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.

OPTICS

Eye-pieces	: Huygenian x10 and x15
Objectives	: Achromatic x10, and x40 (SL)
Magnification	: x100 to x600

As above, but stage fitted with iris diaphragm, Abbe condenser N.A 1.2, with rack and pinion movement.

General Features

• Pressure die-cast parts to ensure strength and uniformity.
• Well proportioned stable, rigid and vertical body inclinable through 90.
• Mechanical tube length 160 mm.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
• High grade achromatic objectives and Huygenian eye-pieces for sharp and aberration free image
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.

OPTICS

Eye-pieces	: Huygenian x10 and x15
Objectives	: Achromatic x10, and x40 (SL)
Magnification	: x100 to x600

As above, but stage fitted with iris diaphragm, Abbe condenser N.A 1.2, with rack and pinion movement.

General Features

• Pressure die-cast parts to ensure strength and uniformity.
• Well proportioned stable, rigid and vertical body inclinable through 90.
• Mechanical tube length 160 mm.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
• High grade achromatic objectives and Huygenian eye-pieces for sharp and aberration free image
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.

OPTICS

Eye-pieces	: Huygenian x10 and x15
Objectives	: Achromatic x10, and x40 (SL)
Magnification	: x100 to x600

Thisis a standardised microscope for medical institutions and pathologicallaboratories. In addition to general specifications for student microscopes:

• Fine motion knob is graduated to read to 0.002 mm.
• Fitted with detachable graduated mechanical stage.
• A sub-stage iris diaphragm with Abbe condenser N.A.1.2 which moves up and down with rack and pinion motion.

OPTICS

Eye Pieces	: Huygenian x5, x10, x15 (any two)
Objectives	: Achromatic x10, x40 (spring loaded) and x100 (spring loaded) oil immersion

General Features

• Pressure die-cast parts to ensure strength and uniformity.
• Well proportioned stable, rigid and vertical body inclinable through 90.
• Mechanical tube length 160 mm.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
• High grade achromatic objectives and Huygenian eye-pieces for sharp and aberration free image
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.

OPTICS

Eye-pieces	: Huygenian x10 and x15
Objectives	: Achromatic x10, and x40 (SL)
Magnification	: x100 to x600

Thisis a standardised microscope for medical institutions and pathologicallaboratories. In addition to general specifications for student microscopes:

• Fine motion knob is graduated to read to 0.002 mm.
• Fitted with detachable graduated mechanical stage.
• A sub-stage iris diaphragm with Abbe condenser N.A.1.2 which moves up and down with rack and pinion motion.

OPTICS

Eye Pieces	: Huygenian x5, x10, x15 (any two)
Objectives	: Achromatic x10, x40 (spring loaded) and x100 (spring loaded) oil immersion

General Features

• Pressure die-cast parts to ensure strength and uniformity.
• Well proportioned stable, rigid and vertical body inclinable through 90.
• Mechanical tube length 160 mm.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
• High grade achromatic objectives and Huygenian eye-pieces for sharp and aberration free image
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.

OPTICS

Eye-pieces	: Huygenian x10 and x15
Objectives	: Achromatic x10, and x40 (SL)
Magnification	: x100 to x600

• Well proportioned stable, rigid and vertical body inclinable through 90.
• Eye tube is inclined at 45.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stop ensuring correct centering.
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.
  OPTICS

Eye-pieces	: Wide Field x10 and x15
Objectives	: Achromatic x4, x10 and x40 (SL)
Magnification	: x40 to x400

General Features

• Pressure die-cast parts to ensure strength and uniformity.
• Well proportioned stable, rigid and vertical body inclinable through 90.
• Mechanical tube length 160 mm.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
• High grade achromatic objectives and Huygenian eye-pieces for sharp and aberration free image
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.

OPTICS

Eye-pieces	: Huygenian x10 and x15
Objectives	: Achromatic x10, and x40 (SL)
Magnification	: x100 to x600

• Well proportioned stable, rigid and vertical body inclinable through 90.
• Eye tube is inclined at 45.
• Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
• Triple revolving nose-piece with international standard threads, with click stop ensuring correct centering.
• Safety stopper to prevent damage to slides and objectives.
• Fixed square stage of 110x110 mm with two nonremovable stage clips.
• Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
• Smooth black or scratch resistant grey epoxy finish.
• Dust cover and cleaning cloth.
• Packed in moulded styrofoam box or wooden cabinet with lock and key.
  OPTICS

Eye-pieces	: Wide Field x10 and x15
Objectives	: Achromatic x4, x10 and x40 (SL)
Magnification	: x40 to x400

Standard laboratory microscopes for routine laboratory work and educational purposes.
General Features :

• Monocular body with tube inclined at 45, rotatable 360,allowing convenient viewing and enabling more than one person to view image without disturbing microscope setting.
• Quadruple nose-piece.
• Coarse and fine focussing adjustment with tension control mechanism.
• Sub-stage condenser N.A. 1.2 with rack and pinion movement.
  OPTICS:


Eye-piece	: WF x10
Objectives	: Achromatic x4, x10, x40 (SL) and x100 (SL) oil immersion.

With plano concave mirror reflector which is replaceable by an electric illuminator, 220V 15 W

Standard laboratory microscopes for routine laboratory work and educational purposes.
General Features :

• Monocular body with tube inclined at 45, rotatable 360,allowing convenient viewing and enabling more than one person to view image without disturbing microscope setting.
• Quadruple nose-piece.
• Coarse and fine focussing adjustment with tension control mechanism.
• Sub-stage condenser N.A. 1.2 with rack and pinion movement.
  OPTICS:


Eye-piece	: WF x10
Objectives	: Achromatic x4, x10, x40 (SL) and x100 (SL) oil immersion.

With plano concave mirror reflector which is replaceable by an electric illuminator, 220V 15 W

Standard laboratory microscopes for routine laboratory work and educational purposes.
General Features :

• Monocular body with tube inclined at 45, rotatable 360,allowing convenient viewing and enabling more than one person to view image without disturbing microscope setting.
• Quadruple nose-piece.
• Coarse and fine focussing adjustment with tension control mechanism.
• Sub-stage condenser N.A. 1.2 with rack and pinion movement.
  OPTICS:


Eye-piece	: WF x10
Objectives	: Achromatic x4, x10, x40 (SL) and x100 (SL) oil immersion.

With 6V-20W halogen lamp, with transformer built in the base, with luminosity control mechanism, giving a sharp and bright image.

Standard laboratory microscopes for routine laboratory work and educational purposes.
General Features :

• Monocular body with tube inclined at 45, rotatable 360,allowing convenient viewing and enabling more than one person to view image without disturbing microscope setting.
• Quadruple nose-piece.
• Coarse and fine focussing adjustment with tension control mechanism.
• Sub-stage condenser N.A. 1.2 with rack and pinion movement.
  OPTICS:


Eye-piece	: WF x10
Objectives	: Achromatic x4, x10, x40 (SL) and x100 (SL) oil immersion.

With 6V-20W halogen lamp, with transformer built in the base, with luminosity control mechanism, giving a sharp and bright image.

ADVANCED MICROSCOPES, XLB SERIES
Professional microscopes for use in biological, medical, industrial laboratories and hospitals etc.
General Features

• Broad, well shaped stand to ensure stability.
• Monocular/binocular head inclined at 45, rotatable 360 and fitted with anti-reflection coated prisms.
• Separate knobs for coarse and fine focussing. Coarse knob is with tension adjustment arrangement. Fine adjustment knob is graduated to 0.002 mm.
• Quadruple nose-piece.
• Large rectangular stage 130 x 120 mm fitted with two non-removable stage clips.
• Detachable mechanical stage with graduated scales and verniers
• Two lens Abbe condenser N.A. 1.2 with iris diaphragm, filter holder and blue filter, movable by rack and pinion mechanism.
• 6 V-20 W halogen lamp with transformer built in the base, with luminosity control regulator.
• Colour corrected optics to provide a flat, high resolution image through parfocal and precentered achromatic objectives and wide-field eye-pieces.
• Safety stopper to prevent damage to slides and
• Supplied complete with mains cable, dust cover, and cleaning cloth .
• Packed in wooden cabinet with lock and key or in Styrofoam box.

Description as above, but with monocular head, inclined at 45 rotatable through 360
OPTICS :

Eye-pieces	: WF x10, WF x 15
Objectives	: Achromatic. x 4, x 10, x 40 (SL) and x 100 (SL) oil immersion.

ADVANCED MICROSCOPES, XLB SERIES
Professional microscopes for use in biological, medical, industrial laboratories and hospitals etc.
General Features

• Broad, well shaped stand to ensure stability.
• Monocular/binocular head inclined at 45, rotatable 360 and fitted with anti-reflection coated prisms.
• Separate knobs for coarse and fine focussing. Coarse knob is with tension adjustment arrangement. Fine adjustment knob is graduated to 0.002 mm.
• Quadruple nose-piece.
• Large rectangular stage 130 x 120 mm fitted with two non-removable stage clips.
• Detachable mechanical stage with graduated scales and verniers
• Two lens Abbe condenser N.A. 1.2 with iris diaphragm, filter holder and blue filter, movable by rack and pinion mechanism.
• 6 V-20 W halogen lamp with transformer built in the base, with luminosity control regulator.
• Colour corrected optics to provide a flat, high resolution image through parfocal and precentered achromatic objectives and wide-field eye-pieces.
• Safety stopper to prevent damage to slides and
• Supplied complete with mains cable, dust cover, and cleaning cloth .
• Packed in wooden cabinet with lock and key or in Styrofoam box.

Description as above, but with monocular head, inclined at 45 rotatable through 360
OPTICS :

Eye-pieces	: WF x10, WF x 15
Objectives	: Achromatic. x 4, x 10, x 40 (SL) and x 100 (SL) oil immersion.

ADVANCED MICROSCOPES, XLB SERIES
Professional microscopes for use in biological, medical, industrial laboratories and hospitals etc.
General Features

• Broad, well shaped stand to ensure stability.
• Monocular/binocular head inclined at 45, rotatable 360 and fitted with anti-reflection coated prisms.
• Separate knobs for coarse and fine focussing. Coarse knob is with tension adjustment arrangement. Fine adjustment knob is graduated to 0.002 mm.
• Quadruple nose-piece.
• Large rectangular stage 130 x 120 mm fitted with two non-removable stage clips.
• Detachable mechanical stage with graduated scales and verniers
• Two lens Abbe condenser N.A. 1.2 with iris diaphragm, filter holder and blue filter, movable by rack and pinion mechanism.
• 6 V-20 W halogen lamp with transformer built in the base, with luminosity control regulator.
• Colour corrected optics to provide a flat, high resolution image through parfocal and precentered achromatic objectives and wide-field eye-pieces.
• Safety stopper to prevent damage to slides and
• Supplied complete with mains cable, dust cover, and cleaning cloth .
• Packed in wooden cabinet with lock and key or in Styrofoam box.
  As above, but with built-in mechanical stage with co-axial movements.

ADVANCED MICROSCOPES, XLB SERIES
Professional microscopes for use in biological, medical, industrial laboratories and hospitals etc.
General Features

• Broad, well shaped stand to ensure stability.
• Monocular/binocular head inclined at 45, rotatable 360 and fitted with anti-reflection coated prisms.
• Separate knobs for coarse and fine focussing. Coarse knob is with tension adjustment arrangement. Fine adjustment knob is graduated to 0.002 mm.
• Quadruple nose-piece.
• Large rectangular stage 130 x 120 mm fitted with two non-removable stage clips.
• Detachable mechanical stage with graduated scales and verniers
• Two lens Abbe condenser N.A. 1.2 with iris diaphragm, filter holder and blue filter, movable by rack and pinion mechanism.
• 6 V-20 W halogen lamp with transformer built in the base, with luminosity control regulator.
• Colour corrected optics to provide a flat, high resolution image through parfocal and precentered achromatic objectives and wide-field eye-pieces.
• Safety stopper to prevent damage to slides and
• Supplied complete with mains cable, dust cover, and cleaning cloth .
• Packed in wooden cabinet with lock and key or in Styrofoam box.
  As above, but with built-in mechanical stage with co-axial movements.

ADVANCED MICROSCOPES, XLB SERIES
Professional microscopes for use in biological, medical, industrial laboratories and hospitals etc.
General Features

• Broad, well shaped stand to ensure stability.
• Monocular/binocular head inclined at 45, rotatable 360 and fitted with anti-reflection coated prisms.
• Separate knobs for coarse and fine focussing. Coarse knob is with tension adjustment arrangement. Fine adjustment knob is graduated to 0.002 mm.
• Quadruple nose-piece.
• Large rectangular stage 130 x 120 mm fitted with two non-removable stage clips.
• Detachable mechanical stage with graduated scales and verniers
• Two lens Abbe condenser N.A. 1.2 with iris diaphragm, filter holder and blue filter, movable by rack and pinion mechanism.
• 6 V-20 W halogen lamp with transformer built in the base, with luminosity control regulator.
• Colour corrected optics to provide a flat, high resolution image through parfocal and precentered achromatic objectives and wide-field eye-pieces.
• Safety stopper to prevent damage to slides and
• Supplied complete with mains cable, dust cover, and cleaning cloth .
• Packed in wooden cabinet with lock and key or in Styrofoam box.
  As per above general description, but with Binocular Head inclined at 45 and rotating 360
  OPTICS :


  Eye-pieces	: WF x10 (paired) and WF x15 (paired)
  Objectives	: Achromatic x4, x10, x40 (SL)and x100 (SL) oil immersion.

  ADVANCED MICROSCOPES, XLB SERIES
  Professional microscopes for use in biological, medical, industrial laboratories and hospitals etc.
  General Features

  • Broad, well shaped stand to ensure stability.
  • Monocular/binocular head inclined at 45, rotatable 360 and fitted with anti-reflection coated prisms.
  • Separate knobs for coarse and fine focussing. Coarse knob is with tension adjustment arrangement. Fine adjustment knob is graduated to 0.002 mm.
  • Quadruple nose-piece.
  • Large rectangular stage 130 x 120 mm fitted with two non-removable stage clips.
  • Detachable mechanical stage with graduated scales and verniers
  • Two lens Abbe condenser N.A. 1.2 with iris diaphragm, filter holder and blue filter, movable by rack and pinion mechanism.
  • 6 V-20 W halogen lamp with transformer built in the base, with luminosity control regulator.
  • Colour corrected optics to provide a flat, high resolution image through parfocal and precentered achromatic objectives and wide-field eye-pieces.
  • Safety stopper to prevent damage to slides and
  • Supplied complete with mains cable, dust cover, and cleaning cloth .
  • Packed in wooden cabinet with lock and key or in Styrofoam box.
    As per above general description, but with Binocular Head inclined at 45 and rotating 360
    OPTICS :


    Eye-pieces	: WF x10 (paired) and WF x15 (paired)
    Objectives	: Achromatic x4, x10, x40 (SL)and x100 (SL) oil immersion.

ADVANCED MICROSCOPES, XLB SERIES
Professional microscopes for use in biological, medical, industrial laboratories and hospitals etc.
General Features

• Broad, well shaped stand to ensure stability.
• Monocular/binocular head inclined at 45, rotatable 360 and fitted with anti-reflection coated prisms.
• Separate knobs for coarse and fine focussing. Coarse knob is with tension adjustment arrangement. Fine adjustment knob is graduated to 0.002 mm.
• Quadruple nose-piece.
• Large rectangular stage 130 x 120 mm fitted with two non-removable stage clips.
• Detachable mechanical stage with graduated scales and verniers
• Two lens Abbe condenser N.A. 1.2 with iris diaphragm, filter holder and blue filter, movable by rack and pinion mechanism.
• 6 V-20 W halogen lamp with transformer built in the base, with luminosity control regulator.
• Colour corrected optics to provide a flat, high resolution image through parfocal and precentered achromatic objectives and wide-field eye-pieces.
• Safety stopper to prevent damage to slides and
• Supplied complete with mains cable, dust cover, and cleaning cloth .
• Packed in wooden cabinet with lock and key or in Styrofoam box.
  As above but fitted with built-in co-axial mechanical stage.


  ADVANCED MICROSCOPES, XLB SERIES
  Professional microscopes for use in biological, medical, industrial laboratories and hospitals etc.
  General Features

  • Broad, well shaped stand to ensure stability.
  • Monocular/binocular head inclined at 45, rotatable 360 and fitted with anti-reflection coated prisms.
  • Separate knobs for coarse and fine focussing. Coarse knob is with tension adjustment arrangement. Fine adjustment knob is graduated to 0.002 mm.
  • Quadruple nose-piece.
  • Large rectangular stage 130 x 120 mm fitted with two non-removable stage clips.
  • Detachable mechanical stage with graduated scales and verniers
  • Two lens Abbe condenser N.A. 1.2 with iris diaphragm, filter holder and blue filter, movable by rack and pinion mechanism.
  • 6 V-20 W halogen lamp with transformer built in the base, with luminosity control regulator.
  • Colour corrected optics to provide a flat, high resolution image through parfocal and precentered achromatic objectives and wide-field eye-pieces.
  • Safety stopper to prevent damage to slides and
  • Supplied complete with mains cable, dust cover, and cleaning cloth .
  • Packed in wooden cabinet with lock and key or in Styrofoam box.
    As above but fitted with built-in co-axial mechanical stage.


BIOSTAR MICROSCOPES CXL SERIES
High performance microscopes with co-axial focussing for maximum ease of operation and halogen illumination for brighter and sharper images
General Features

• 45 inclined monocular/binocular head rotatable through 360 for convenience of working and multiple viewing.
• A robust arm with focussing knobs on both sides based on a 4-stage gear reduction system travelling on ball guides. The co-axial focussing system provides a high degree of working convenience.
• A large stage fitted with built-in mechanical stage having low drive co-axial knob for X - Y movements in horizontal plane.
• A sub-stage condenser with iris diaphragm and filter holder, with rack & pinion movement.
• A low friction four-nose objective turret on a dust proof carrier provides lasting smooth rotation. The built-in click stops bring each objective to perfect
• alignment.
• High degree performance and resolution.
• With 6V-20W halogen light source built in the base with on/off switch and electronic light intensity regulator. The lamp is easily replaceable.
• Complete with power cord.
• Packed in moulded Styrofoam box or in wooden cabinet with lock and key.

OPTICS :

Eye-pieces	: WF x10 (paired for binocular head) with high eyepoint.
Objectives	: Achromatic x4, x10, x40 (SL) and x100 (SL) oil immersion.

BIOSTAR MICROSCOPES CXL SERIES
High performance microscopes with co-axial focussing for maximum ease of operation and halogen illumination for brighter and sharper images
General Features

• 45 inclined monocular/binocular head rotatable through 360 for convenience of working and multiple viewing.
• A robust arm with focussing knobs on both sides based on a 4-stage gear reduction system travelling on ball guides. The co-axial focussing system provides a high degree of working convenience.
• A large stage fitted with built-in mechanical stage having low drive co-axial knob for X - Y movements in horizontal plane.
• A sub-stage condenser with iris diaphragm and filter holder, with rack & pinion movement.
• A low friction four-nose objective turret on a dust proof carrier provides lasting smooth rotation. The built-in click stops bring each objective to perfect
• alignment.
• High degree performance and resolution.
• With 6V-20W halogen light source built in the base with on/off switch and electronic light intensity regulator. The lamp is easily replaceable.
• Complete with power cord.
• Packed in moulded Styrofoam box or in wooden cabinet with lock and key.

OPTICS :

Eye-pieces	: WF x10 (paired for binocular head) with high eyepoint.
Objectives	: Achromatic x4, x10, x40 (SL) and x100 (SL) oil immersion.
