BIOSTAR MONOCULAR MICROSCOPE |
|
BIOSTAR MICROSCOPES CXL SERIES
High performance microscopes with co-axial focussing for
maximum ease of operation and halogen illumination for
brighter and sharper images
General Features
- 45 inclined monocular/binocular head rotatable
through 360 for convenience of working and
multiple viewing.
- A robust arm with focussing knobs on both sides
based on a 4-stage gear reduction system travelling
on ball guides. The co-axial focussing system
provides a high degree of working convenience.
- A large stage fitted with built-in mechanical stage
having low drive co-axial knob for X - Y movements
in horizontal plane.
- A sub-stage condenser with iris diaphragm and
filter holder, with rack & pinion movement.
- A low friction four-nose objective turret on a dust
proof carrier provides lasting smooth rotation. The
built-in click stops bring each objective to perfect
- alignment.
- High degree performance and resolution.
- With 6V-20W halogen light source built in the base
with on/off switch and electronic light intensity
regulator. The lamp is easily replaceable.
- Complete with power cord.
- Packed in moulded Styrofoam box or in wooden
cabinet with lock and key.
OPTICS :
| Eye-pieces |
: WF x10 (paired for binocular head) with high eyepoint. |
| Objectives |
: Achromatic x4, x10, x40 (SL) and x100 (SL) oil immersion. |
|
|
| |
|
| View Cart |
| |
| |
| |
| |
|
|
| |
|
|
|
|
